In vehicle development, more and more measurement data is being generated. They form the basis for testing and optimizing new functions. However, the amount of data collected has long been too large for manual evaluation. That's why IAV developed the tool Zio Insight: It is easy to use and extracts the maximum amount of information from the available data. The extensive evaluation and visualization options make even complex relationships understandable. For example, a simple traffic light system indicates whether there are problems with certain measurement series. In all evaluations, it does not matter whether the data comes from a real measurement or a simulation.
What makes IAV Zio Insight special
- Mature preprocessing and analysis functions for simple representations of complex evaluations – for output in Excel, HTML, or PPT, or as digital artifacts.
- Easily load existing evaluation scripts from the script repository or spontaneously create individual evaluations – no programming skills required, no development environment needed. Reusable.
- Processing of automotive data – whether time-continuous signals or diagnostic shots, measurement data or simulation data, with the possibility of enrichment from program- and data statuses.
- Individual evaluation of tests as well as statistical evaluation of collected data sets – with limit monitoring for a quick focus on the essentials.
- Easy switch from local desktop use to high-performance calculation in the cloud. Automatic evaluation of measurement data in the cloud – at AWS, IAV, or on-premise.
- Seamless integration into a complete development framework along the V-process is possible.
Central repository for evaluation scripts
- IAV Zio Insight offers a centrally maintained repository of pre-built evaluation scripts that every developer can access.
- The scripts are defined by the users themselves – using a graphical user interface and without requiring programming skills.
- It is possible to automatically create scripts from formalized test specifications.
- Over time, a library of scripts is created that can be used company-wide for data evaluation.
- IAV can also provide its customers with customized scripts as an additional service upon request.
High efficiency and extensive automation
The evaluation of the data can take place locally on the developer's computer or in the cloud. Switching between both options is seamless with a click of the mouse. Analyses in the cloud can be conducted significantly faster than on a regular PC: On one hand, higher computing power is usually available there. On the other hand, IAV Zio Insight in the cloud performs pre-calculations based on the already available data. If additional measurements are added later, only these need to be newly analyzed – a process that can be automatically triggered by defining appropriate conditions. The data can be hosted via IAV at AWS, any other cloud provider, or on-premise at the customer's site.
Focus on structured metadata
In addition to the actual measurement values, structured metadata of the measurements is crucial for efficient evaluation of experiments.
- IAV Zio Insight offers the ability to automatically generate metadata, for example, from known file types or the measurement data itself.
- Another unique feature is the AI-supported search for measurement data: From any search text, the tool automatically generates the appropriate database query with metadata. This allows measurements to be found and evaluated more quickly.
Complete toolchain along the V-model
The results of the evaluations can be retrieved in various formats such as Excel, HTML, or PowerPoint. They can also be directly imported into the IAV tool Result for result management and further processing.
Here, another strength of IAV Zio Insight becomes apparent: It is part of a toolchain that supports all development steps along the V-model – from requirements management to result management and final documentation. All tools have been successfully in use at IAV for years.
